ÖLFLEX CLASSIC 110 4G6,0 R100

ÖLFLEX® CLASSIC 110 CYScreened PVC control cable with transparent outer sheath, VDE registered, screened, flexible and numbered for various applications, U0/U: 300/500VCPR: see www.lappkabel.dkVDE reg. no. 7030EMC-compliantInterference signalsGood chemical resistanceSpace-saving installation due to small cable diametersHigh electrical performance due to 4 kV test voltagePlant engineeringIndustrial machineryHeating and air-conditioning systemsConveyor and transport systemsIn EMC-sensitive environments (electromagnetic compatibility)Flame-retardant according IEC 60332-1-2Good chemical resistance.High degree of screening low transfer impedance (max. 250 O/km at 30 MHz)Fine-wire strand made of bare copper wiresPVC insulation LAPP P8/1Cores twisted in layersPVC inner sheath, greyTinned-copper braidingPVC outer sheath, transparent Core identification code: Black with white numbers acc. to VDE 0293-1Conductor stranding: Fine wire according to VDE 0295, class 5/IEC 60228 class 5Minimum bending radius: Occasional flexing: 20 x outer diameterFixed installation: 6 x outer diameterNominal voltage: U0/U: 300/500 VTest voltage: 4000 VProtective conductor: G = with GN-YE protective conductor. X = without GN-YETemperature range: Occasional flexing: -5°C to +70°CFixed installation: -40°C to +80°C
